Wet End / Paper Feeding

1. Hydraulic Mill Roll Stand (with Trolley) – Qty: 5 sets – Type: 1800W01M
2. Auto Splicer – Qty: 5 sets – Type: 1800JKJ (Auto Splicer spec referenced as 1800JZJ150)

Preheating / Single Facer Section

1. Liner Preheater – Qty: 2 sets – Type: 1800W20 (Dia. 900 mm)
2. Medium Preheater – Qty: 2 sets – Type: 1800W21 (Dia. 900 mm)
   • Sound proof room – Qty: 2
   • Cassette trolley – Qty: 2

Bridge / Web Handling

1. Over Bridge (Two layer) – Qty: 1 set – Type: 1800W03
2. Bridge correction machine control system (Double Layers) – Qty: 1 set – Type: 1800JP

Heating / Gluing / Double Facer

1. Triplex Preheater – Qty: 1 set – Type: 1800W22
2. Double Glue Machine – Qty: 1 set – Type: 1800W04 / 1800W04H
3. Double Facer – Qty: 1 set – Type: 1800W05G (Hot plates chrome treated)
4. Main Transmission – Qty: 1 set – Type: 1800W09

Dry End / Cutting / Slitting / Stacking

1. Rotary Shear – Qty: 1 set – Type: 1800W10 / 1800QD
2. NC Slitter Scorer (Thin Blade) – Qty: 1 set – Type: 1800W06M (configuration: 5 knives / 8 scorers)
3. Double NC Cut Off – Qty: 1 set – Type: 1800W07
4. Double Stacker – Qty: 1 set

• Sheet Delivery Stacker – Lower layer
• Basket Down Stacker / Auto Down Stacker – Upper layer (Type shown as 2000W14)

End-of-Line & Utilities (Included)

1. Pallet Inserter (semi-automatic) – End of line
2. Steam Boiler – IVAR (Process steam supply)

• The package also includes a pallet inserter and a boiler for generating process steam. Therefore, it is a complete set. The dry end has been dismantled and stored. The wet end remains in place and connected.
