LABEL FINISHING & CONVERTING MACHINE

Manufacturer: CARTES
Model: GE362VR
Year: 2017
Made in: Italy
CE Marked: Yes

Technical Specifications

Maximum Web Width: 360 mm
Minimum Web Width: 100 mm
Maximum Speed: 150 m/min
Power: 25 kW
Power Supply: 400 V
Frequency: 50/60 Hz
Machine Weight: 3,980 kg

Maximum Unwind/Rewind Roll Diameter: up to 600 mm / 800 mm optional*
Maximum Matrix Roll Diameter: 650 mm*
Minimum Slitting Width: 15 mm*
Semi-Rotary Repeat Length: up to 350 mm*
Flexible Die Thickness: 0.2–2.0 mm*

Machine Configuration

• Unwinding Unit
• Web Guiding System
• Corona Treatment Unit
• Flexographic Printing / Coating Unit
• Laminating Station
• Translative / Semi-Rotary Die-Cutting Unit
• Rewinding Unit
• Camera Inspection System

Machine Status

• Machine is currently in full production.
• The machine can be inspected under power at any time.

Machine Counter

• Power-On Hours: 14,887 hours
• Working Hours: 6,815 hours
• Rewinder Counter: 628,395 meters

Availability

Expected availability: End of Q1 2027

Typical Applications

Suitable for finishing and converting roll-fed labels, including:

• Self-Adhesive Labels
• Product Labels
• Food & Beverage Labels
• Cosmetic Labels
• Pharmaceutical Labels
• Industrial Labels
• Laminated Labels
• Varnished Labels
• Die-Cut Roll Labels
• Pressure-Sensitive Labels
