• Manufacturer: Windmöller & Hölscher
• Model: Olympia 736 ST
• Year of production: 1986
• Refurbished by Garant with newer technology
• Color change modification
• Electrical panel control replaced with Siemens
• BST web guiding system, purchased in 2018
• Inspection camera
• Section 5 converted into a glue section
• Additional guide rollers installed
• Two guide rollers added in front of the knife section for processing thinner paper
• Inspection platform installed on top of the machine
• Display above the rewinder showing printing speed

Replaced Parts

• Drive belt for the rubber paper pulling rollers
• Drive belt for the rewinder rotation
• Bearings on the unwinder

Main Technical Specification

• Central drum
• 6 colors
• Gear-driven system
• Water-based inks
• Max. material width: 1320 mm
• Max. printing width: 1270 mm
• Min. – max. print repeat: 300 – 910 mm
• Gear pitch: 10 mm
• Max. mechanical printing speed: 250 m/min

Suitable Materials

• Paper: 50 – 130 g/m²
• HDPE: 0.010 – 0.040 mm
• Polyethylene / LDPE: 0.020 – 0.150 mm
• Laminated films: up to 0.100 mm
• PP
• Cellophane and similar materials: 0.012 – 0.100 mm

Unwinder / Rewinder

• Max. reel diameter unwinder: 1000 mm
• Max. reel diameter rewinder: 1000 mm
• Inner core diameter unwinder: 76 mm
• Inner core diameter rewinder: 76 mm
• Min. – max. web tension unwinder: 25 – 270 N
• Min. – max. web tension rewinder: 30 – 350 N

Printing Cylinders

• 16 cylinders in total : 5 x 310, 6 x 520, 5 x 580

Anilox Rolls

• 7 anilox rolls in total: 3 x 80, 1 x 120, 1 x 160, 2 x 200

Gears

• 157 gears in total
• 7 x 31, 8 x 32, 6 x 33, 6 x 34, 6 x 35, 6 x 36, 6 x 37, 6 x 38, 6 x 39, 4 x 40, 5 x 42, 6 x 44, 6 x 46, 6 x 49, 5 x 50, 6 x 52, 5 x 54, 5 x 57, 6 x 58, 5 x 59, 6 x 60, 6 x 61, 8 x 62, 5 x 64, 6 x 66, 1 x 70, 3 x 71, 3 x 75, 3 x 76

Sleeves Included – Inner / Outer Diameter

• 78 sleeves in total
• 9 x 310/320, 1 x 310/330, 5 x 310/340, 3 x 310/350, 4 x 310/360, 3 x 310/390, 5 x 310/380, 5 x 310/400, 2 x 310/420, 2 x 310/440, 1 x 310/450, 2 x 310/460, 1 x 310/490, 4 x 310/500, 4 x 520/520, 1 x 520/560, 5 x 520/570, 4 x 580/590, 2 x 580/600, 3 x 580/610, 2 x 580/620, 1 x 580/640, 4 x 580/660, 2 x 580/750, 3 x 580/760

Additional Information

• Registration accuracy front/back: ± 1 mm
• Siemens 5 electronic system
• Explosion-proof: to be confirmed
• Chiller available, not connected
• Gas burner drying system available, not connected because the machine is currently used for paper
• Manuals and electrical diagrams available
• Overall dimensions (L x W x H): 17 x 8.30 x 5.20 m
• Machine can be seen in production
• Immediately available
