Flexotecnica Tachys – 8-Color CI Flexographic Printing Press

Manufacturer: Flexotecnica
Model: Tachys
Year: 2003
Machine Type: Geared Central Impression (CI) Flexographic Printing Press
Number of Colors: 8

Technical Specifications

• Maximum Web Width: 950 mm
• Maximum Printing Width: 900 mm
• Printing Repeat: 280 – 650 mm
• Maximum Speed: 250 m/min, depending on the product
• Gear Pitch: 10 mm
• Electrical Drying System
• Closed Ink Chambers
• Doctor Blade System
• Electrical Ink Pumps
• Quick Anilox and Sleeve Change System

Unwinding & Rewinding

• Double Simple Unwinder with Tension Control
• Double Automatic Turret Rewinder
• 3 Tension Control Zones

Web Handling & Treatment

• Corona Treatment
• BST Web Guide before Central Drum
• BST Web Guide before Rewinder
• Banana Roller
• Chill Roller
• Slitting Unit
• Central Drum Temperature Control

Camera & Inspection System

• 3-Chip Camera System
• Additional Inspection Point

Included Equipment

• 238 Sleeves
• 23 Anilox Rollers
• Including 4 New High-Resolution Anilox Rollers (400)

Machine Dimensions

• Length: 14,480 mm
• Height: 4,820 mm
• Total Width: approx. 5,500 mm

Machine Condition

• Machine is in daily production
• Machine is in good working condition
