Bobst F&K 20SIX S

Bobst F&K 20SIX S

Details

Referenz ID

Kategorie

PP-48048

Flexodruck

Hersteller

Bobst

Modell

F&K 20SIX S

Jahr

2015

Farbe

Geschwindigkeit

Max. Format

Min. Format

Bedingung

Ort

Verfügbarkeit

350

m/min

800x1300 mm

320x650 mm

Gut

Europa

Sofort

Beschreibung

8-Color Flexo Rotary Printing Machine
Counter reading: 73,000 printing kilometers
TECHNICAL DATA
✓ Number of printing units: 8 colors
✓ Print width: max. 1,250 mm
✓ Material width: min. 650 mm, max. 1,300 mm
✓ Print length: min. 320 mm, max. 800 mm
✓ Mechanical performance: max. 350 m/min
✓ Roll diameter: max. 1,020 mm (unwinder/rewinder)
✓ Core sizes: 70, 76, 100, 150 mm
EQUIPMENT
✓ Automatic roll change for unwinder & rewinder
✓ Column lifting system for shaft unwinder/rewinder
✓ Digital printing unit control with servo drive
✓ Central impression cylinder system (temperature controlled)
✓ Automatic color supply and cleaning system AUTOCLEAN
✓ Web control system before printing unit
✓ Video web inspection system with 1-chip camera
✓ Compressed air cleaning unit for optimal print quality
HIGHLIGHTS
✓ High-quality precision machine for professional packaging printing
✓ 8-color configuration for complex printing jobs
✓ Fully automatic operation with Operator Control System
✓ Modern process control with real-time monitoring
✓ Machine plan and nameplate available
✓ Ready for immediate operation after installation
ACCESSORIES FOR BOBST 20SIX (MACHINE 11)
The machine comes with comprehensive accessories:
✓ Sleeves: actual print width from 60 to 1.250 mm are available
✓ Print cylinders: actual print length from 440 to 660 mm available
✓ 5 knifes
✓ Original documentation
STATUS
Machine currently in operation - printing customer orders Inspection and demonstration possible by appointment, but orders can be transferred to another machine => machine can be deinstalled at any moment
